Solar Inverter ON OFF Grid Solar inverter DC AC 5KW 10KW 15KW 20KW 30KW
HFP4850S80-H is a high-performance solar inverter designed to meet the needs of residential and commercial photovoltaic (PV) systems. With its advanced technology, flexible design, and user-friendly interface, this inverter provides a reliable and efficient solution for harnessing the power of the sun.
O'Cell is committed to providing high-quality solar inverter solutions that help to power a greener future. With its advanced technology,flexible design, and user-friendly interface, [Inverter Model] is the ideal choice for anyone looking to harness the power of the sun and make the switch to clean, renewable energy.
Solar Inverter Parameters
| Model | HFP4850S80-H |
| Battery Input |
| Battery type | Sealed,Flood,GEL,LFP,Ternary |
| Rated Battery Input Voltage | 48V(Minimum Startup Voltage 44V) |
| Hybrid Charging Maximum Charing Current | 80A |
| Battery Voltage Range | 40Vdc~60Vdc±0.6Vdc(Undervoltage Warning/Shutdown Voltage/Overvoltage Warning/Overvoltage Recovery...) |
| Solar Input |
| Maximum PV Open-Circuit Voltage | 500Vdc |
| PV Working Voltage Range | 120-500Vdc |
| MPPT Voltage Range | 120-450Vdc |
| Maximum PV Input Current | 22A |
| Maximum PV Input Power | 5500W |
| Maximum PV Charging Current | 80A |
| AC Input(generator/grid) |
| Mains Maximum Charging Current | 60A |
| Rated Input Voltage | 220/230Vac |
| Input Voltage Range | UPS Mains Mode:(170Vac~280Vac)±2% APL Generator Mode:(90Vac~280Vac)±2% |
| Frequency | 50Hz/60Hz(Automatic Detection) |
| Mains Charing Efficiency | >95% |
| Switch Time(bypass and inverter) | 10ms(Typical Value) |
| Maximum Bypass Overload Current | 40A |
| AC Output |
| Output Voltage Waveform | Pure Sine Wave |
| Rated Output Voltage(Vac) | 230Vac(200/208/220/240Vac) |
| Rated Output Power(VA) | 5000(4350/4500/4750/5000) |
| Rated Output Power(W) | 5000(4350/4500/4750/5000) |
| Peak Power | 10000VA |
| On-load Motor Capacity | 4HP |
| Output Frequency Range(HZ) | 50Hz±0.3Hz/60Hz±0.3Hz |
| Maximum Efficiency | >92% |
| No-load Loss | Non Energy-saving Mode:≤50W Energy-saving Mode:≤25W(Manual Setup) |
| General |
| Number of parallel/split phases | 1-6PCS |
| Certificate | CE(IEC62109-1)/CETL(UL 1741 C22.2 NO.107.1) |
| EMC Certification Level | EN61000,C2 |
| Working Temperature Range | -10℃~55℃ |
| Storage Temperature Range | -25℃~60℃ |
| Humidity Range | 5% to 95%(Conformal Coating Protection) |
| Dimensions | 426mm*322mm*124mm |
Solar Inverter Size
Q: What is a solar inverter?
A: A solar inverter is an electronic device that converts the direct current (DC) electricity
generated by solar panels into alternating current (AC) electricity, which can be used by homes and businesses.
Q: What are the different types of solar inverters?
A: There are two main types of solar inverters: string inverters and
microinverters. String inverters are connected to multiple solar panels and convert the combined DC output into AC. Microinverters are connected to individual solar panels and convert the DC output from each panel into AC.
Q: How does a solar inverter work?
A: A solar inverter takes the DC electricity generated by the solar panels and converts it into
AC electricity using electronic circuitry. This AC electricity can then be used by homes and businesses, or fed back into the
grid.
Q: What is the difference between a grid-tied and off-grid solar inverter?
A: A grid-tied solar inverter is connected to the
electrical grid and sends excess energy back to the grid when the solar panels produce more energy than is being used. An off-grid solar inverter is not connected to the electrical grid and must store excess energy in batteries for later use.
Q: What are the benefits of a solar inverter?
A: Solar inverters have several benefits, including:
-Increased energy efficiency: By converting DC to AC, solar inverters increase the efficiency of the solar panels and allow for more energy to be generated and used.
-Improved safety: Solar inverters are designed to ensure that the electricity generated by the solar panels is safe for homes and businesses to use.
-Monitoring capabilities: Many solar inverters come equipped with monitoring capabilities, allowing homeowners to track theirenergy production and usage.
Q: What should I look for when choosing a solar inverter?
A: When choosing a solar inverter, consider the following factors:
-Compatibility with your solar panel system
-Efficiency and reliability of the inverter
-Monitoring capabilities
-Warranty and customer support
-Cost and budget.
